NWA/WAC Series CLI Reference Guide 81
CHAPTER 15
System Remote Management
This chapter shows you how to determine which services/protocols can access which NWA/WAC
zones (if any) from which computers.
Note: To allow the NWA/WAC to be accessed from a specified computer using a service,
make sure you do not have a service control rule or to-NWA/WAC rule to block that
traffic.
15.1 System Timeout
There is a lease timeout for administrators. The NWA/WAC automatically logs you out if the
management session remains idle for longer than this timeout period. The management session
does not time out when a statistics screen is polling.
Each user is also forced to log in the NWA/WAC for authentication again when the reauthentication
time expires.
15.2 HTTP/HTTPS Commands
The following table describes the commands available for HTTP/HTTPS. You must use the
configure terminal command to enter the configuration mode before you can use these
commands.
Table 48 Command Summary: HTTP/HTTPS
COMMAND DESCRIPTION
[no] ip http authentication auth_method Sets an authentication method used by the HTTP/HTTPS
server. The
no command resets the authentication
method used by the HTTP/HTTPS server to the factory
default (
default).
auth_method: The name of the authentication method.
You may use 1-31 alphanumeric characters,
underscores(_), or dashes (-), but the first character
cannot be a number. This value is case-sensitive.
[no] ip http port <1..65535> Sets the HTTP service port number. The
no command
resets the HTTP service port number to the factory
default (80).
[no] ip http secure-port <1..65535> Sets the HTTPS service port number. The
no command
resets the HTTPS service port number to the factory
default (443).
