Chapter 12 Wireless Load Balancing
NWA/WAC Series CLI Reference Guide
72
load-balancing alpha <1..255> Sets the load balancing alpha value.
When the AP is balanced, then this setting delays a client’s
association with it by this number of seconds.
Note: This parameter has been optimized for the NWA/WAC and
should not be changed unless you have been specifically
directed to do so by ZyXEL support.
load-balancing beta <1..255> Sets the load balancing beta value.
When the AP is overloaded, then this setting delays a client’s
association with it by this number of seconds.
Note: This parameter has been optimized for the NWA/WAC and
should not be changed unless you have been specifically
directed to do so by ZyXEL support.
load-balancing sigma <51..100> Sets the load balancing sigma value.
This value is algorithm parameter used to calculate whether an
AP is considered overloaded, balanced, or underloaded. It only
applies to ‘by traffic mode’.
Note: This parameter has been optimized for the NWA/WAC and
should not be changed unless you have been specifically
directed to do so by ZyXEL support.
load-balancing timeout <1..255> Sets the length of time that an AP retains load balancing
information it receives from other APs within its range.
load-balancing liInterval <1..255> Sets the interval in seconds that each AP communicates with the
other APs in its range for calculating the load balancing
algorithm.
Note: This parameter has been optimized for the NWA/WAC and
should not be changed unless you have been specifically
directed to do so by ZyXEL support.
load-balancing kickInterval <1..255> Enables the kickout feature for load balancing and also sets the
kickout interval in seconds. While load balancing is enabled, the
AP periodically disconnects stations at intervals equal to this
setting.
This occurs until the load balancing threshold is no longer
exceeded.
show load-balancing config Displays the load balancing configuration.
show load-balancing loading Displays the loading status per radio (underload / balance /
overload) when you enable the load balancing fuction.
[no] load-balancing activate Enables load balancing. Use the no parameter to disable it.
Table 40 Command Summary: Load Balancing (continued)
COMMAND DESCRIPTION
