NWA/WAC Series CLI Reference Guide 31
CHAPTER 4
Status
This chapter explains some commands you can use to display information about the NWA/WAC’s
current operational state.
Here are examples of the commands that display the CPU and disk utilization.
Table 7 Status Show Commands
COMMAND DESCRIPTION
show boot status Displays details about the NWA/WAC’s startup state.
show cpu status Displays the CPU utilization.
show disk Displays the disk utilization.
show extension-slot Displays the status of the extension card slot and the USB ports and the names of
any connected devices.
show led status Displays the status of each LED on the NWA/WAC.
show mac Displays the NWA/WAC’s MAC address.
show mem status Displays what percentage of the NWA/WAC’s memory is currently being used.
show power mode Displays the NWA/WAC’s power status.
Full - the NWA/WAC reveives power using a power adaptor and/or through a PoE
switch/injector using IEEE 802.3at PoE plus.
Limited - the NWA/WAC reveives power through a PoE switch/injector using IEEE
802.3af PoE even when it is also connected to a power source using a power
adaptor.
When the NWA/WAC is in limited power mode, the NWA/WAC throughput
decreases and has just one transmitting radio chain.
It always shows Full if the NWA/WAC does not support power detection.
show ram-size Displays the size of the NWA/WAC’s on-board RAM.
show serial-number Displays the serial number of this NWA/WAC.
show socket listen Displays the NWA/WAC’s listening ports
show socket open Displays the ports that are open on the NWA/WAC.
show system uptime Displays how long the NWA/WAC has been running since it last restarted or was
turned on.
show version Displays the NWA/WAC’s model, firmware and build information.
Router# show cpu status
CPU utilization: 0 %
CPU utilization for 1 min: 0 %
CPU utilization for 5 min: 0 %
Router# show disk
No. Disk Size(MB) Usage
===========================================================================
1 image 65 82%
2 onboard flash 154 36%
