Chapter 5 Interfaces
NWA/WAC Series CLI Reference Guide
35
[no] metric <0..15> Sets the interface’s priority relative to other interfaces. The
lower the number, the higher the priority.
[no] mss <536..1460> Specifies the maximum segment size (MSS) the interface is
to use. MSS is the largest amount of data, specified in
bytes, that the interface can handle in a single,
unfragmented piece. The
no command has the interface
use its default MSS.
[no] mtu <576..1500> Specifies the Maximum Transmission Unit, which is the
maximum number of bytes in each packet moving through
this interface. The NWA/WAC divides larger packets into
smaller fragments. The
no command resets the MTU to
1500.
[no] shutdown Deactivates the specified interface. The
no command
activates it.
traffic-prioritize {tcp-ack|dns} bandwidth
<0..1048576> priority <1..7> [maximize-
bandwidth-usage];
Applies traffic priority when the interface sends TCP-ACK
traffic, or traffic for resolving domain names. It also sets
how much bandwidth the traffic can use and can turn on
maximize bandwidth usage.
traffic-prioritize {tcp-ack|dns} deactivate Turns off traffic priority settings for when the interface
sends the specified type of traffic.
[no] upstream <0..1048576> Specifies the upstream bandwidth for the specified
interface. The
no command sets the upstream bandwidth
to 1048576.
manager ap vlan vlan-id <1..4094> <tag|untag> When the NWA/WAC is in standalone or controller mode,
this sets the AP’s VLAN identification number and sets it to
send tagged or untagged packets.
manager ap vlan ip address [ ip subnet_mask | dhcp] Sets the management IPv4 address for the NWA/WAC.
manager ap vlan [no] ipv6 address ipv6_addr/prefix Sets the IPv6 address and the prefix length for the LAN
interface of the NWA/WAC.
The no command removes the IPv6 address settings.
manager ap vlan [no] ipv6 dhcp6 {address-request |
client}
Set the NWA/WAC to act as a DHCPv6 client or get this
interface’s IPv6 address from a DHCPv6 server.
The no command sets the NWA/WAC to not get this
interface’s IPv6 address from the DHCPv6 server.
manager ap vlan [no] ipv6 dhcp6-request-object
dhcp6_profile
For a DHCPv6 client interface, sets the profile of DHCPv6
request settings that determine what additional information
to get from the DHCPv6 server.
The no command removes the DHCPv6 request settings
profile.
manager ap vlan [no] ipv6 enable Enables IPv6 stateless auto-configuration on the NWA/
WAC. The NWA/WAC will generate an IPv6 address itself
from a prefix obtained from an IPv6 router in the network.
The no command disables IPv6 stateless auto-
configuration.
manager ap vlan [no] ipv6 gateway ipv6_addr Sets the IPv6 address of the default outgoing gateway.
The no command removes the IPv6 gateway settings.
manager ap vlan [no] ipv6 nd ra accept Sets the IPv6 interface to accept IPv6 neighbor discovery
router advertisement messages.
The no command sets the IPv6 interface to discard IPv6
neighbor discovery router advertisement messages.
Table 9 interface General Commands: Basic Properties and IP Address Assignment (continued)
COMMAND DESCRIPTION
