Chapter 8 Wireless LAN Profiles
NWA/WAC Series CLI Reference Guide
61
8.5 MAC Filter Profile Commands
The following table identifies the values required for many of these commands. Other input values
are discussed with the corresponding commands.
The following table describes the commands available for MAC filter profile management. You must
use the
configure terminal command to enter the configuration mode before you can use
these commands.
8.5.1 MAC Filter Profile Example
The following example creates a MAC filter profile with the name ‘MACFILTER01’..
Table 27 Input Values for General MAC Filter Profile Commands
LABEL DESCRIPTION
macfilter_profile_name The MAC filter profile name. You may use 1-31 alphanumeric characters,
underscores (
_), or dashes (-), but the first character cannot be a number.
This value is case-sensitive.
description Sets the description of the MAC address. You may use up to 60 alphanumeric
characters, underscores (
_), or dashes (-). This value is case-sensitive.
Table 28 Command Summary: MAC Filter Profile
COMMAND DESCRIPTION
show wlan-macfilter-profile {all | rule_count |
[macfilter_profile_name]}
Displays the MAC filter profile(s).
all: Displays all profiles.
rule_count: Displays how many MAC filter profiles are created
on the NWA/WAC.
macfilter_profile_name: Displays the specified profile.
wlan-macfilter-profile rename
macfilter_profile_name1
macfilter_profile_name2
Gives an existing MAC filter profile (macfilter_profile_name1)
a new name (macfilter_profile_name2).
[no] wlan-macfilter-profile
macfilter_profile_name
Enters configuration mode for the specified MAC filter profile. Use
the no parameter to remove the specified profile.
filter-action {allow | deny} Permits the wireless client with the MAC addresses in this profile
to connect to the network through the associated SSID; select
deny to block the wireless clients with the specified MAC
addresses.
The default is set to deny.
[no] mac_addr [description description] Specifies a MAC address associated with this profile. You can also
set a description for the MAC address. Enter up to 60 characters.
Spaces and underscores allowed.
exit Exits configuration mode for this profile.
Router(config)# wlan-macfilter-profile MACFILTER01
Router(config-macfilter-profile)# filter-action deny
Router(config-macfilter-profile)# 01:02:03:04:05:06 description MAC01
Router(config-macfilter-profile)# 01:02:03:04:05:07 description MAC02
Router(config-macfilter-profile)# 01:02:03:04:05:08 description MAC03
Router(config-macfilter-profile)# exit
Router(config)#
