Chapter 1 Command Line Interface
NWA/WAC Series CLI Reference Guide
19
1.6.2 List of Sub-commands or Required User Input
To view detailed help information for a command, enter <command> <sub command> ?.
Figure 6 Help: Sub-command Information Example
Figure 7 Help: Required User Input Example
1.6.3 Entering Partial Commands
The CLI does not accept partial or incomplete commands. You may enter a unique part of a
command and press
[TAB] to have the NWA/WAC automatically display the full command.
For example, if you enter
config and press [TAB] , the full command of configure automatically
displays.
If you enter a partial command that is not unique and press
[TAB], the NWA/WAC displays a list of
commands that start with the partial command.
Figure 8 Non-Unique Partial Command Example
1.6.4 Entering a ? in a Command
Typing a ? (question mark) usually displays help information. However, some commands allow you
to input a ?, for example as part of a string. Press [CTRL+V] on your keyboard to enter a ? without
the NWA/WAC treating it as a help query.
1.6.5 Command History
The NWA/WAC keeps a list of commands you have entered for the current CLI session. You can use
any commands in the history again by pressing the up () or down () arrow key to scroll through
the previously used commands and press
[ENTER].
Router(config)# ip telnet server ?
;
<cr>
port
rule
|
Router(config)# ip telnet server
Router(config)# ip telnet server port ?
<1..65535>
Router(config)# ip telnet server port
Router# c [TAB]
clear configure copy
Router# co [TAB]
configure copy
