Chapter 12 VPN
P-792H v2 User’s Guide
181
12.9.9.1 ID Type and Content Examples
Two IPSec routers must have matching ID type and content configuration in order
to set up a VPN tunnel.
The two P-792H v2s in this example can complete negotiation and establish a VPN
tunnel.
The two P-792H v2s in this example cannot complete their negotiation because P-
792H v2 B’s Local ID type is IP, but P-792H v2 A’s Peer ID type is set to E-
mail. An “ID mismatched” message displays in the IPSEC LOG.
Table 52 Peer ID Type and Content Fields
PEER ID
TYPE=
CONTENT=
IP Type the IP address of the computer with which you will make the VPN
connection or leave the field blank to have the P-792H v2 automatically
use the address in the Secure Gateway Address field.
DNS Type a domain name (up to 31 characters) by which to identify the
remote IPSec router.
E-mail Type an e-mail address (up to 31 characters) by which to identify the
remote IPSec router.
The domain name or e-mail address that you use in the Content field is
used for identification purposes only and does not need to be a real
domain name or e-mail address. The domain name also does not have to
match the remote router’s IP address or what you configure in the
Secure Gateway Address field below.
Table 53 Matching ID Type and Content Configuration Example
P-792H V2 A P-792H V2 B
Local ID type: E-mail Local ID type: IP
Local ID content:
tom@yourcompany.com
Local ID content: 1.1.1.2
Peer ID type: IP Peer ID type: E-mail
Peer ID content: 1.1.1.2 Peer ID content: tom@yourcompany.com
Table 54 Mismatching ID Type and Content Configuration Example
P-792H V2 A P-792H V2 B
Local ID type: IP Local ID type: IP
Local ID content: 1.1.1.10 Local ID content: 1.1.1.10
Peer ID type: E-mail Peer ID type: IP
Peer ID content: aa@yahoo.com Peer ID content: N/A
