Appendix A Product Specifications
P-792H v2 User’s Guide
405
Security User Authentication (PAP, CHAP) with PPP (RFC 1334, RFC 1994)
Microsoft CHAP
Stateful packet inspection firewall
Content filter
Prevent Denial of service
Access control of service
Real-time attack alert and log
Network Management Web-based Configuration
Command-line interface
Password-protected Telnet support
SNMP MIB I /MIB II support
TFTP & FTP firmware upgrade and configuration backup
VPN IPSec VPN support
5 VPN tunnels
IKE/ Manual Key
DES/3DES/AES Encryption (software)
MD5/ SHA1 Authentication
FQDN
NETBIOS pass-through for IPSec
IPSec VPN keep-alive
IPSec NAT Traversal
Diagnostics
Capabilities (for the
following circuitry)
FLASH memory
SDSL circuitry
RAM
LAN port
Others DNS Proxy
UNIX syslog
Table 144 Firmware (continued)
