![Zyxel P-792H v2 [319/472] Figure 151 menu 12 bridge static route setup](/img/pdf.png)
Zyxel P-792H v2 [319/472] Figure 151 menu 12 bridge static route setup
![Zyxel P-792H v2 [319/472] Figure 151 menu 12 bridge static route setup](/views2/1169438/page319/bg13f.png)
Chapter 29 Static Route Setup
P-792H v2 User’s Guide
319
29.2 Bridge Static Route Setup
Enter 3 from menu 12. Select one of the bridge static routes as shown next to
configure IP static routes in menu 12.3.
Figure 151 Menu 12.3: Bridge Static Route Setup
Now, enter the index number of the static route that you want to configure.
Figure 152 Menu 12.3.1: Edit Bridge Static Route
The following table describes the fields in this screen.
Menu 12.3 - Bridge Static Route Setup
1. ________
2. ________
3. ________
4. ________
Menu 12.3.1 - Edit Bridge Static Route
Route #: 1
Route Name= ?
Active= No
Ether Address= ?
IP Address=
Gateway Node= 1
Table 121 Menu 12.3.1: Edit Bridge Static Route
FIELD DESCRIPTION
Route # This is the index number of the static route that you chose in menu 12.
Route Name Enter a descriptive name for this route. This is for identification purposes
only.
Active This field allows you to activate/deactivate this static route.
Ether Address This parameter specifies the MAC address of the final destination.
IP Address Enter the IP address of the gateway. The gateway is an immediate
neighbor of your P-792H v2 that will forward the packet to the
destination. On the LAN, the gateway must be a router on the same
segment as your P-792H v2; over the WAN, the gateway must be the IP
address of one of the remote nodes.
Gateway Node Press [SPACE BAR] and then [ENTER] to select the number of the remote
node that is the gateway for this static route.
Once you have completed filling in this menu, press [ENTER] at the message “Press
ENTER to Confirm…” to save your configuration, or press [ESC] to cancel.
