CHAPTER 25
WAN Setup
Use this menu to configure the DSL connection, and traffic redirect interface.
25.1 WAN Setup
From the main menu, enter 2 to open menu 2.
Figure 136 Menu 2: WAN Setup
The following table describes the fields in this screen.
Menu 2 - WAN Setup
Service Mode= 2wire DSL Mode = ATM
Service Type= Server
Rate Adaption= Enable
Transfer Max Rate(Kbps)= 5696
Transfer Min Rate(Kbps)= 192
Standard Mode= ANSI(ANNEX_A)
Wan Backup Setup:
Check Mechanism = DSL Link
Check WAN IP Address1 = 0.0.0.0
Check WAN IP Address2 = 0.0.0.0
Check WAN IP Address3 = 0.0.0.0
KeepAlive Fail Tolerance = 0
Recovery Interval(sec) = 0
ICMP Timeout(sec) = 0
Traffic Redirect = No
Table 110 Menu 2: WAN Setup
FIELD DESCRIPTION
Service Mode The P-792H v2 uses 2-wire mode for the DSL connection.The maximum
data rate is up to 5.7 Mbps.
DSL Mode Press [SPACE BAR] to select the transfer mode you want to use.
PTM (Packet Transfer Mode): The P-792H v2 uses EFM TC layer for data
transmission over the DSL port.
ATM (Asynchronous Transfer Mode): The P-792H v2 uses ATM TC layer
for data transmission over the DSL port.
