Chapter 35 Firmware and Configuration File Maintenance
P-792H v2 User’s Guide
377
8 Enter “quit” to exit the ftp prompt. The P-792H v2 will automatically restart after a
successful restore process.
35.4.2 Restore Using FTP Session Example
Figure 205 Restore Using FTP Session Example
Refer to Section 35.3.5 on page 372 to read about configurations that disallow
TFTP and FTP over WAN.
35.4.3 Restore Via Console Port
Restore configuration via console port by following the HyperTerminal procedure
shown next. Procedures using other serial communications programs should be
similar.
1 Display menu 24.6 and enter “y” at the following screen.
Figure 206 System Maintenance: Restore Configuration
2 The following screen indicates that the Xmodem download has started.
Figure 207 System Maintenance: Starting Xmodem Download Screen
ftp> put config.rom rom-0
200 Port command okay
150 Opening data connection for STOR rom-0
226 File received OK
221 Goodbye for writing flash
ftp: 16384 bytes sent in 0.06Seconds 273.07Kbytes/sec.
ftp>quit
Ready to restore Configuration via Xmodem.
Do you want to continue (y/n):
Starting XMODEM download (CRC mode) ...CCCCCCCCC
