Chapter 28 Remote Node Setup
P-792H v2 User’s Guide
315
28.7 Advance Setup Options
You can edit advanced setup options when the encapsulation is PPPoE. Move the
cursor to the Edit Advance Options field in menu 11.1 (only for remote node 1),
then press [SPACE BAR] to select Yes. Press [ENTER]
to open Menu 11.8 -
Advanced Setup Options.
Figure 148 Menu 11.8: Advance Setup Options
The following table describes the fields in this menu.
Menu 11.8 - Advance Setup Options
PPPoE pass-through= No
Table 119 Menu 11.8: Advance Setup Options
FIELD DESCRIPTION
PPPoE pass-
through
In addition to the ZyXEL Device's built-in PPPoE client, you can
enable PPPoE Passthrough to allow up to ten hosts on the LAN to use
PPPoE client software on their computers to connect to the ISP via
the ZyXEL Device. Each host can have a separate account and a
public WAN IP address.
PPPoE pass through is an alternative to NAT for applications where
NAT is not appropriate.
Disable PPPoE passthrough if you do not need to allow hosts on the
LAN to use PPPoE client software on their computers to connect to
the ISP.
Once you have completed filling in this menu, press [ENTER] at the message “Press
ENTER to Confirm...” to save your configuration and return to menu 11.1, or press [ESC]
at any time to cancel.
