Zyxel P-792H v2 [382/472] Uploading via console port
![Zyxel P-792H v2 [382/472] Uploading via console port](/views2/1169438/page382/bg17e.png)
Chapter 35 Firmware and Configuration File Maintenance
P-792H v2 User’s Guide
382
35.5.7 Uploading Via Console Port
FTP or TFTP are the preferred methods for uploading firmware to your P-792H v2.
However, in the event of your network being down, uploading files is only possible
with a direct connection to your P-792H v2 via the console port. Uploading files via
the console port under normal conditions is not recommended since FTP or TFTP is
faster. Any serial communications program should work fine; however, you must
use the Xmodem protocol to perform the download/upload.
35.5.8 Uploading Firmware File Via Console Port
1 Select 1 from Menu 24.7 – System Maintenance – Upload Firmware to display
Menu 24.7.1 - System Maintenance - Upload System Firmware, and then follow
the instructions as shown in the following screen.
Figure 213 Menu 24.7.1 As Seen Using the Console Port
2 After the "Starting Xmodem upload" message appears, activate the Xmodem
protocol on your computer. Follow the procedure as shown previously for the
HyperTerminal program. The procedure for other serial communications programs
should be similar.
Menu 24.7.1 - System Maintenance - Upload System Firmware
To upload system firmware:
1. Enter "y" at the prompt below to go into debug mode.
2. Enter "atur" after "Enter Debug Mode" message.
3. Wait for "Starting XMODEM upload" message before activating
Xmodem upload on your terminal.
4. After successful firmware upload, enter "atgo" to restart the router.
Warning: Proceeding with the upload will erase the current system
firmware.
Do You Wish To Proceed:(Y/N)
