P-792H v2 User’s Guide
291
CHAPTER 24
General Setup
Use this menu to set up device mode, dynamic DNS and administrative
information.
24.1 Configuring General Setup
1 Enter 1 in the main menu to open Menu 1 - General Setup.
2 The Menu 1 - General Setup screen appears, as shown next. Fill in the required
fields.
Figure 134 Menu 1: General Setup
The following table describes the fields in this menu.
Menu 1 - General Setup
System Name= P-792H v2
Location=
Contact Person's Name=
Domain Name=
First DNS Server= 0.0.0.0
Secondary DNS Server= 0.0.0.0
Third DNS Server= 0.0.0.0
Edit Dynamic DNS= No
Route IP= Yes
Bridge= No
Table 108 Menu 1: General Setup
FIELD DESCRIPTION
System Name Choose a descriptive name for identification purposes. It is
recommended you enter your computer’s “Computer name” in this field.
This name can be up to 30 alphanumeric characters long. Spaces are not
allowed, but dashes “-” and underscores "_" are accepted.
Location Enter a descriptive name for the place where the P-792H v2 is located.
You can enter up to 31 characters, or you can leave this field blank.
