6. Troubleshooting
This chapter provides information about troubleshooting your ProSAFE Dual Band Wireless-N
Access Point WNDAP360. After each problem description, instructions are given to help you
diagnose and solve the problem. For the common problems listed, go to the section indicated.
• Is the wireless access point on?
Go to Basic Functioning on page 104.
• Have I connected the wireless access point correctly?
Go to Basic Functioning on page 104.
• I cannot access the Internet or the LAN.
Go to You Cannot Access the Internet or the LAN from a Wireless-Capable Computer on
page 105.
• I cannot access the wireless access point from a browser.
Go to You Cannot Configure the Wireless Access Point from a Browser on page 106.
• A time-out occurs.
Go to When You Enter a URL or IP Address a Time-Out Error Occurs on page 107.
• I cannot remember the wireless access point’s configuration password.
Go to Change the Administrator Password on page 68.
• I want to clear the configuration and start over again.
Go to Restore the Wireless Access Point to the Factory Default Settings on page 66.
• The date or time is not correct.
Go to Problems with Date and Time on page 108.
The wireless access point provides a packet capture tool that enables you to perform
problem diagnoses. For information about how to use this tool, go to Use the Packet Capture
Tool on page 109.
