Wireless Configuration and Security

ProSAFE Dual Band Wireless-N Access Point WNDAP360

Configure WPA-PSK, WPA2-PSK, and WPA-PSK & WPA2-PSK

WPA-PSK, WPA-PSK, and WPA-PSK & WPA2-PSK authentication use a pre-shared key

(PSK, also called a passphrase or a network key) and do not require authentication from a

RADIUS server.

The selections that are available from the Data Encryption drop-down list depend on the type

of WPA-PSK authentication that you select from the Network Authentication drop-down list

and are shown in the following table.

• WPA-PSK

Figure 24.

• WPA2-PSK

Figure 25.

• WPA-PSK & WPA2-PSK

Figure 26.
