Management
74
ProSAFE Dual Band Wireless-N Access Point WNDAP360
The following table explains the fields of the Wireless Stations Details screen:
Table 19. Wireless Stations Details Fields
Field Description
MAC Address The MAC address of the wireless station.
BSSID The BSSID that the wireless station is using.
SSID The SSID that the wireless station is using.
Channel The channel that the wireless station is using.
Rate The transmit data rate in Mbps of the wireless station.
State The features that are enabled on the wireless station.
Type The authentication and encryption type that the wireless station is using.
AID The associated identifier (AID) of the wireless station.
Mode The wireless mode in which the wireless station is operating.
Status The wireless status of the wireless station (Associated).
RSSI The received signal strength indicator (RSSI) of the wireless station.
Idle Time The time since the last frame was received from the wireless station.
Tx Sequence The sequence number of the last frame that was transmitted to the wireless station.
Rx Sequence The sequence number of the last frame that was received from the wireless station.
Capability The capability summary of the wireless station that was detected during association.
Cipher The cipher that is used by the wireless station and that defines the type of encryption.
SNR The signal-to-noise ratio (SNR) that indicates how much the signal of the wireless
station has been corrupted by noise.
Recv. Bytes The number of bytes received on the wireless station since it last started up.
Trans. bytes The number of bytes transmitted by the wireless station since it last started up.
Assoc. Time Stamp The time when these details of the wireless station were retrieved.
IP Address The IP address of the wireless station.
Channel Width The channel width at which the wireless station operates.
