Domain Name
The DFL-600 can provide a domain name to
computers on your network. This domain name
suffix can be provided automatically by your
ISP, or you can enter it statically here. This
suffix will then be automatically added to URL
requests for access to your ISP’s servers.
Primary DNS Server
This is the IP address of a server on the Internet
that provides the service of changing text URLs
into IP address for sites on the Internet. The IP
address of this server is provided by your ISP.
Secondary DNS
Server
This is the IP address of a second DNS server, to
be used in case of a problem with the Primary
DNS Server, above. A secondary DNS server IP
address is optional.
