VPN-PPTP Settings
The Point-to-Point Tunneling Protocol (PPTP) is another method of
establishing a secure tunnel between the DFL-600 and a remote gateway.
The PPTP Settings page allows you to enable or disable PPTP on the DFL-
600.
PPTP Pass Through
Click Enable to allow PPTP packets to pass
through the router to the destination computer on
your LAN. When IPSec Pass-through is
enabled, the DFL-600 will allow PPTP packets
to reach their destination computer on your
LAN.
PPTP Status
PPTP can be Enabled or Disabled by clicking
the appropriate click-box and the clicking the
Apply.
Starting IP Address
This allows you to specify a range of IP
addresses for clients on your network that can
use the PPTP protocol. If you have only one IP
address, enter this address in both the Starting
IP Address and Ending IP Address fields.
Ending IP Address
This allows you to specify a range of IP
addresses for clients on your network that can
use the PPTP protocol. If you have only one IP
address, enter this address in both the Starting
IP Address and Ending IP Address fields.
