Enter a Domain Name that you want the DFL-600 to scan for and prevent
PCs on websites that contain that word in their URLs from accessing PCs on
your LAN.
Blocked MAC Addresses
The DFL-600 will allow you to make a list of MAC addresses for which
outgoing packets will be filtered. MAC (Media Access Control) addresses
are the physical addresses that are assigned to networking devices by their
respective manufacturers. These addresses are 12 hexadecimal digits long
and are in the form 01-23-45-67-89-AB − where the numerals 0-9 and the
letters A-F are used.
Clicking on the “Blocked MAC” link on the Out Policy page will open the
following page.
