Update File
Enter the full DOS path and filename to the new
firmware file on your local hard drive. For
example, if the file is in the root directory of
your C drive, enter C:\newfile.had and click the
OK button to begin the file transfer.
Browse
If you are unsure about the location of the new
firmware file on your local hard drive, click the
Browse button to open a Windows Explorer
window to look for this file.
Tools − Ping
Ping is a small program that will send a series of test packets to a network
device and ask for the device to send the packets back to the source. It is
very useful to determine if a given network device is properly connected to
the network and is operating properly.
To ping an IP address, enter the IP address in the IP address field, enter the
number of packets you want to send in the Count number field (three is
usually sufficient) and click the Apply button. The results will be displayed
in the field with a scroll bar to the right, as shown below.
