intruder’s IP address will remain in the Intruder Blacklist for an additional
amount of time. While the intruder’s IP address is on the DFL-600’s Intruder
Blacklist, that IP address is blocked from sending packets through the DFL-
600.
Source IP
The IP address of a computer or device that will
not be allowed to make a connection from the
WAN to the DFL-600 is displayed here.
Destination IP
The IP address of the computer or device that the
intruder has tried to connect to is displayed here.
Destination
Port/Transport Type
The port number or ICMP Type that an intruder
used to attempt to make a connection is
displayed here.
Blocking Time
This is the amount of time the Source IP has
been blocked.
