Policy (Firewall Settings)
Policy Rules
The DFL-600 allows you to establish a period of time that a policy rule will
be active or enforced. In addition, you can enable or disable a policy rule
without changing that rule’s configuration. This is useful when you need to
troubleshoot access problems for a PC on your LAN.
The schedule for a policy rule is specified on the Policy Rules page, as
shown below.
Enter a name for the policy rule you want to configure in the Policy Name
field. This name will not appear in the Policy Table, but will appear in the
Always Schedule, as shown below. The One Time and One Week
schedules, along with the policy configuration pages shown below, identify
policies by their index number.
