User’s Manual of STW-16P8 & STW-1622HP

- STP, IEEE 802.1d Spanning Tree Protocol

- RSTP, IEEE 802.1w Rapid Spanning Tree Protocol

 Port mirroring to monitor the incoming or outgoing traffic on a particular port

 Provides port mirror (Many-to-1)

 Loopback protection to avoid broadcast loops

 Quality of Service

 2 priority queues on all switch ports

 Traffic classification

- Port-based priority

- IEEE 802.1p-based priority

- IP TOS / DSCP-based priority

- TCP / UDP port-based QoS

 Strict priority and Weighted Round Robin (WRR) CoS policies

 Multicast

 Supports IGMP Snooping v1 and v2

 Security

 Physical port to MAC address binding

 TCP/UDP port number filter: Forwarding or discarding typical network applications

 Port mirroring to monitor the incoming or outgoing traffic on a particular port

 Management

 Switch Management Interfaces

- Web switch management

- SNMP v1 switch management

 Supports DHCP Option82 and DHCP Relay

 Firmware upload/download via HTTP

 Network Time Protocol (NTP)

 Hardware reset button for system reboot or reset to factory default

 BEWARD smart discovery utility
