User’s Manual of STW-16P8 & STW-1622HP
12
1.5 Product Specifications
Product
STW-1622HP
STW-16P8
Hardware Specifications
10/100Mbps Copper Ports
16 10/100BASE-TX RJ45 Auto-MDI/MDI-X ports
Gigabit Copper Ports
2 10/100/1000BASE-T RJ45
Auto-MDI/MDI-X ports
None
SFP/mini-GBIC Slots
2 1000BASE-X SFP interfaces, shared
with Port-17 to Port-18
None
Switch Architecture
Store-and-Forward
Switch Fabric
7.2Gbps / non-blocking
3.2Gbps.
Throughput
5.35Mpps@64Bytes
2.38Mpps.
Address Table
4K entries, automatic source address learning and ageing
Share Data Buffer
2.75Mb embedded memory for packet buffers
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
1536 Bytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
Dimensions (W x D x H)
440 x 200 x 44.5 mm, 1U height
440 x 120 x 44 mm (1U height)
Weight
2.55kg
1.75 kg
LED
System:
Power (Green)
10/100BASE-TX RJ45 Interfaces
(Port1 to Port16):
10/100Mbps LNK/ACT (Green)
PoE In-Use (Orange)
10/100/1000BASE-T RJ45 / SFP
Interfaces
(Port17 to Port18):
LNK/ACT (Green)
100/1000 (Green)
PoE Usage
50W, 100W, 150W, 190W (Orange)
System:
Power (Green)
10/100BASE-TX RJ45 Interfaces
(Port1 to Port16):
10/100Mbps LNK/ACT (Green)
PoE In-Use (Orange)
Power Requirements
100~240V AC, 50/60Hz, 4A
100-240V AC, 50-60 Hz, 1A
Power Consumption
Max. 240 watts / 816 BTU
123.5 watts / 420BTU
ESD Protection
2KV DC
None
Power over Ethernet
PoE Standard
IEEE 802.3af / 802.3at PoE / PSE
IEEE 802.3af PoE / PSE
PoE Power Supply Type
End-span
PoE Power Output
Per Port 56V DC, Max. 30.8 watts
Per Port 48V DC, Max. 15.4 watts
Power Pin Assignment
1/2(+), 3/6(-)
