User’s Manual of STW-16P8 & STW-1622HP
94
The Page includes the following fields:
Object
Description
Aging time(ms)
Use higher Output Queue Aging Time will have bad utilization of shared buffer
and performance. Possible modes are:
Disabled: Disable Output Queue Aging Time operation
200: Configure 200ms for the Output Queue Aging Time.
400: Configure 400ms for the Output Queue Aging Time.
600: Configure 600ms for the Output Queue Aging Time.
800: Configure 800ms for the Output Queue Aging Time.
VLAN Striding
Indicates the VLAN Striding operation. Possible modes are:
Enabled: Switch will forward a uni-cast packet to the destination
port. No matter whether the destination port is in the same VLAN
group or not.
Disabled: Disable VLAN Striding operation
IGMP Snooping
Indicates the IGMP Snooping operation. Possible modes are:
Enabled: Enable IGMP Snooping operation
Disabled: Disable IGMP Snooping operation
IGMP Leave Packet
Indicates the IGMP Leave Packet operation. Possible modes are:
Enabled: Enable IGMP Leave Packet operation to send IGMP leave
packet to IGMP router ports
Disabled: Disable IGMP Leave Packet operation
VLAN Uplink Setting
Select Uplink list for this port table, this function allows different VLAN use their
individual uplink port to forward packets.
Buttons
: Click to apply changes
