User’s Manual of STW-16P8 & STW-1622HP
38
4.3.1 Port Configuration
This page displays current port configurations and status. Ports can also be configured here. The table has one row for each
port on the selected switch in a number of columns, which are:
The Port Configuration screens in Figure 4-3-1 appear.
Figure 4-3-1 Port Settings Page Screenshot
The page includes the following fields:
Object
Description
Tx/Rx Ability
Indicates the port state operation. Possible statuses are:
Enable - Start up the port manually.
Disable – Shut down the port manually.
