User’s Manual of STW-16P8 & STW-1622HP

 Software Version

The version of software

 Idle Time Security

Set idle time and behavior.

Buttons

: Click to apply changes

4.2.2 IP Configurations

The IP configuration includes the IP Address, Subnet Mask and Gateway. The configured column is used to view or change the

IP configuration. Fill out the IP Address, Subnet Mask and Gateway for the device. The screens in Figure 4-2-2 appear.

Figure 4-2-2 IP Address Setting Page Screenshot

The page includes the following fields:

Object

Description

 IP Address

Provide the IP address of this switch in dotted decimal notation.

 Subnet Mask

Provide the subnet mask of this switch in dotted decimal notation.

 Gateway

Provide the IP address of the router in dotted decimal notation.

 IP Configure

Indicate the IP address mode operation. Possible modes are:

Static: Enable Static IP mode operation.

DHCP: Enable DHCP client mode operation.

Buttons

: Click to apply changes
