Moxa UC-8416-T-LX [39/90] How to check the connection
![Moxa UC-8418-T-LX [39/90] How to check the connection](/views2/1199789/page39/bg27.png)
UC-8410/8416/8418/8430 Managing Communication
4-12
How to check the connection
Once you’ve set up a PPP connection, there are some steps you can take to test the connection. First, type:
/sbin/ifconfig
(The folder ifconfig may be located elsewhere, depending on your distribution.) You should be able to see all
of the network interfaces that are UP. ppp0 should be one of them, and you should recognize the first IP
address as your own In addition, the “P-t-P address” (or point-to-point address) is the address of your server.
Here’s what it looks like on one machine:
lo Link encap Local Loopback
inet addr 127.0.0.1 Bcast 127.255.255.255 Mask 255.0.0.0
UP LOOPBACK RUNNING MTU 2000 Metric 1
RX packets 0 errors 0 dropped 0 overrun 0
ppp0 Link encap Point-to-Point Protocol
inet addr 192.76.32.3 P-t-P 129.67.1.165 Mask 255.255.255.0
UP POINTOPOINT RUNNING MTU 1500 Metric 1
RX packets 33 errors 0 dropped 0 overrun 0
TX packets 42 errors 0 dropped 0 overrun 0
Now, type:
ping z.z.z.z
where z.z.z.z is the address of your name server. This should work. Here’s what the response could look like:
waddington:~$p ping 129.67.1.165
PING 129.67.1.165 (129.67.1.165): 56 data bytes
64 bytes from 129.67.1.165: icmp_seq=0 ttl=225 time=268 ms
64 bytes from 129.67.1.165: icmp_seq=1 ttl=225 time=247 ms
64 bytes from 129.67.1.165: icmp_seq=2 ttl=225 time=266 ms
^C
--- 129.67.1.165 ping statistics ---
3 packets transmitted, 3 packets received, 0% packet loss
round-trip min/avg/max = 247/260/268 ms
waddington:~$
Try typing:
netstat -nr
You should see three routes, similar to the following:
Kernel routing table
Destination Gateway Genmask Flags Metric Ref Use
iface
129.67.1.165 0.0.0.0 255.255.255.255 UH 0 0 6
ppp0
127.0.0.0 0.0.0.0 255.0.0.0 U 0 0 0 lo
0.0.0.0 129.67.1.165 0.0.0.0 UG 0 0 6298
ppp0
If your output looks similar, but does not have the destination 0.0.0.0 line (which refers to the default route
used for connections), you may have run pppd without the ‘defaultroute’ option. At this point you can try using
Telnet, ftp, or finger, bearing in mind that you will need to use numeric IP addresses unless you’ve set up
/etc/resolv.conf correctly.
