UC-8410/8416/8418/8430 Managing Communication
4-21
secret /etc/openvpn/secrouter.key
cipher DES-EDE3-CBC
auth MD5
tun-mtu 1500
tun-mtu-extra 64
ping 40
up /etc/openvpn/tap0-br.sh
Next, modify the routing table in the /etc/openvpn/tap0-br.sh script file.
#---------------------------------- Start----------------------------
#!/bin/sh
# /etc/openvpn/tap0-br.sh
# value after “-net” is the subnet behind the remote peer
route add -net 192.168.2.0 netmask 255.255.255.0 dev br0
#---------------------------------- end -----------------------------
Note: Select cipher and authentication algorithms by specifying “cipher” and “auth”. To see with algorithms
are available, type:
# openvpn --show-ciphers
# openvpn --show—auths
4. After configuring the remote peer, we can load the bridge into kernel, reconfigure eth1, and enable IP
forwarding on both OpenVPN machine.
# /etc/openvpn/openvpn-bridge start
Next, start both OpenVPN peers,
# openvpn --config /etc/openvpn/tap0-br.conf &
If you see the line “Peer Connection Initiated with 192.168.8.173:5000” on each machine, the connection
between OpenVPN machines has been established successfully on UDP port 5000.
Note: You can create link symbols to enable the /etc/openvpn/openvpn-bridge script at boot time:
# ln -s /etc/openvpn/openvpn-bridge /etc/rc.d/rc3.d/S32vpn-br
# ln -s /etc/openvpn/openvpn-bridge /etc/rc.d/rc6.d/K32vpn-br
5. On each OpenVPN machine, check the routing table by typing the command:
# route
Destination Gateway Genmsk Flags Metric Ref Use Iface
192.168.4.0 * 255.255.255.0 U 0 0 0 br0
192.168.2.0 * 255.255.255.0 U 0 0 0 br0
192.168.8.0 * 255.255.255.0 U 0 0 0 eth0
Interface eth1 is connected to the bridging interface br0, to which device tap0 also connects, whereas the
virtual device tun sits on top of tap0. This ensures that all traffic from internal networks connected to
interface eth1 that come to this bridge write to the TAP/TUN device that the OpenVPN program monitors.
Once the OpenVPN program detects traffic on the virtual device, it sends the traffic to its peer.
6. To create an indirect connection to Host B from Host A, add the following routing item:
route add –net 192.168.4.0 netmask 255.255.255.0 dev eth0
To create an indirect connection to Host A from Host B, add the following routing item:
route add –net 192.168.2.0 netmask 255.255.255.0 dev eth0
Now ping Host B from Host A by typing:
ping 192.168.4.174
