UC-8410/8416/8418/8430 Programmer's Guide
5-22
To cross compile:
Debian:~# make
Upload the binary to target and run it with following command
Run the Qt application with assigned input and VGA output:
root@Moxa:/tmp# export QWS_MOUSE_PROTO=IntelliMouse:/dev/input/mouse0 ;
root@Moxa:/tmp# ./hello -qws -geometry 1024x768 -display voyagerlib:/dev/fb0 &
You can also run the second Qt application on another VGA output:
root@Moxa:/tmp# export QWS_MOUSE_PROTO=IntelliMouse:/dev/input/mouse1 ;
root@Moxa:/tmp# ./hello2 -qws -geometry 1024x768 -display voyagerlib:/dev/fb1 &
NOTE Refer to the Qt-embedded Web site, http://qt.nokia.com/doc/4.6/index.html, for more details on Qt
programming ,
