MC-7270-MP-T Series Hardware Introduction
2-4
LED Indicators
LED Name LED Color LED Function
Power
(on front panel)
Green Power is on and functioning normally
Off Power is off or power error exists
Storage
(on front panel)
Red (on) Storage disk is functioning properly
Red (blinking) Storage disk is accessing data
Off No activity
LAN (1 to 4)
(on connectors)
Green 100 Mbps Ethernet mode
Yellow 1000 Mbps (Gigabit) Ethernet mode
Off No activity or 10 Mbps Ethernet mode
Storage
(on storage tray)
Red (on) Storage disk is functioning properly
Red (blinking) Storage disk is being accessed
Red (off) No activity
Blue (on) w/ SATA power
Real Time Clock
The embedded computer’s real-time clock is powered by a lithium battery. We strongly recommend that you do
NOT replace the lithium battery yourself. If the battery needs to be changed, contact the Moxa RMA service
team at http://www.moxa.com/rma/about_rma.aspx
.
ATTENTION
Used batteries are environmentally hazardous material. Dispose of them in the proper manner.
WARNING
There is a risk of explosion if the wrong type of battery is used. To avoid this potential danger, always be sure
to use the correct type of battery. Contact the Moxa RMA service team if you have any questions about
replacing your battery.
