MPC-2000 Series Hardware Hardware Installation and Connection

3-10

Powering On the MPC-2000 Series

1. Connect the MPC-2000 series display to a power source, do one of the following:

• Connect the terminal block to the MPC-2000 Series DC Euroblock terminal (located on the bottom

panel).

• Connect the MPC-2000 series to a power source using the AC power cord provided.

2. Touch the MENU button (on the lower right hand corner of the display panel) for about one second to turn

on the MPC-2000 series.

NOTE

It takes between 10

– 30 seconds for the system to complete the start-up process.

Powering Off the MPC-2000 Series

To power off the MPC-2000 series panel computer, touch the MENU button for about four seconds. Depending

on the power management settings you configure in the operating system, the MPC-2000 series may enter the

standby, hibernation, or system shutdown mode.

To force the MPC-2000 series to shut down, touch the MENU button for about 10 seconds.

NOTE

If the MPC

-2000 series is powered using a DC converter, the INFO dialog displays the Error status for AC

input

power

(as shown in the following figure). This does not affect the normal operation of the MPC-2000 series.

SavvyTouch Display Controls

The MPC-2000 series comes with five SavvyTouch display controls on the front panel. These intelligent controls

turn on as your hand draws near the area of the panel where they are located.

MENU/Power Control

On the MPC-2000 series, the MENU button also serves as the power button. To turn on or turn off the

MPC-2000 series, press the Menu button for about four seconds. After the system is powered up, the MENU

button turns green. To power off the MPC-2000 Series, press the MENU button for about four seconds, and then

choose to enter standby, hibernation, or system shutdown mode (the available choices may be configured

using your operating system’s power management settings). If you encounter technical problems, press and

hold the MENU button for 10 seconds to force a hard shutdown.
