4) YELLOW LED – Indicates there is a possible problem. A

“Pending” DTC is present and/or some of the vehicle‟s emission

monitors have not run their diagnostic testing.

5) RED LED – Indicates there is a problem in one or more of

the vehicle‟s systems. The red LED is also used to show that

DTCs are present. DTCs are shown on the Scan Tool‟s display.

In this case, the MIL lamp on the vehicle‟s instrument panel

will light steady on.

6) One-Click I/M Readiness Key – Quick-checks State

Emissions readiness and drive cycle verification.

7) ESC BUTTON – Cancels a selection (or action) from a

menu or returns to the previous screen.

8) LEFT SCROLL BUTTON – When look up DTC

definitions, moves to previous character and views additional

information on previous screens if DTC definition covers more

than one screen; deselect all marked PID data when viewing or

recording customized live data list; views previous frames of

recorded data when playing back live data. It is also used to

update DTC library when pressed.

9) HELP BUTTON – Provides help information and Code

Breaker function.

10) UP SCROLL BUTTON – Moves up through menu and

submenu items in menu mode. When more than one screen of

data is retrieved, moves up through the current screen to the

previous screens for additional data.

11) OK BUTTON – Confirms a selection (or action) from a

menu.

12) RIGHT SCROLL BUTTON – When look up DTC

definitions, moves to next character and view additional

information on next screens if DTC definition covers more than

one screen; selects/deselects PID data when viewing or
