Compression IGN Required Monitors
√
MIS
√
BP
√
FUEL
√
EGS
√
CCM
√
PM
√
HCCAT
√
EGR
√
NCAT
3) Allowed INC Monitors
From Configure Monitors screen, use the UP/DOWN scroll button to
select Allowed INC Monitors, and press the OK button.
Emissions tests vary depending on the geographic or regional area in
which the vehicle is registered. So the scan tool provides a more
flexible way to meet different standards, which allows the user to
select 0, 1, 2, 3 „not complete‟ monitors in test.
4) Reset Factory Default
From Configure Monitors screen, use the UP/DOWN scroll button to
select Reset Factory Default, and press the OK button.
It will restore the default configuration settings in the Configure
Monitors menu, and delete any customized settings. In this case,
Spark IGN Required Monitors and Compression IGN Required
Monitors will include all the available monitors, and the Allowed
INC Monitors will be set to 1.
The tool will display an information message to ask for your
confirmation. Select Yes to proceed and No to exit without change.
Unit of Measure
Metric is the default measurement unit.
1) From System Setup screen, use the UP/DOWN scroll button to
select Unit of Measure and press the OK button.
