Autel Autolink AL519 [41/73] Recording data
![Autel Autolink AL519 [41/73] Recording data](/views2/1200925/page41/bg29.png)
40
Figure 5.19
5) Use the ESC button to return to previous menu.
Recording Data
The Record Data function allows recording vehicle modules’
Parameter Identification (PID) data to help diagnose
intermittent vehicle problems. A recording includes 5 frames of
live data before trigger event and several frames after trigger
event.
There are two trigger modes used to record data:
A. Manual Trigger - allows user to press the OK button to start
recording.
B. DTC Trigger - automatically records PID data when a fault that
causes a DTC to set is detected by vehicle.
CAUTION: DO NOT try to drive and operate the scan tool at the
same time! Always have another person operate the scan tool
while driving.
To record live data, use the UP/DOWN scroll button to select
Record Data from Live Data menu and press the OK button.
( Figure 5.12)
Recording Complete Data Set
1) To record complete set of live data, use the UP/DOWN scroll
button to select Complete Data Set from Record Data menu
and press the OK button.
………………….Live Data 4 .
DTC_CNT 0
FUELSYS2 0L
ETC(℃) -40 ?
SHRTFT1 (%) 99.2
