Autel Autolink AL519 [20/73] Key beep set

2) From Unit of Measure screen, use the UP/DOWN scroll button

to select the desired unit of measurement. (Figure 3.6 )

Figure 3.6

3) Press the OK button to save your selection and return to previous

menu.

Key Beep Set

This function allows you to turn on/off the build-in speaker for key

pressing.

 The default setting is Beep On.

1) From System Setup screen, use the UP/DOWN scroll button to

select Key Beep Set and press the OK button.

2) From Key Beep Set menu, use the UP/DOWN scroll button to

select Beep ON or Beep OFF to turn on/off the beep.

Figure 3.7

Unit of Measure 1/2

 English

 Metric ?

Key Beep Set 1/2

 Beep ON

 Beep OFF ?
