Autel Autolink AL519 [23/73] Update mode

Figure 3.10

3) Double press ESC to return to previous menu.

C. LED Test

The LED Test function verifies if the I/M Readiness LED indicator

lamps are functioning properly.

1) Use the UP/DOWN scroll button to select LED Test from the

Tool Self-test menu, and then press the OK button.

2) In the LED Test menu, use the UP/DOWN scroll button to

select one or more LED lamps to check. The LED should turn

on or off according to the selected commands.

Figure 3.11

3) When completed, press the ESC button to exit.

Update Mode

This function allows you to update the scan tool software and DTC

library through a computer.

Keyboard Test

Press any key to

start test

key:

Double [ESC] to return

LED Test 1/3

RED LED ON

YELLOW LED ON

GREEN LED ON
