63
5.10 Modules Present
The Modules Present function allows viewing of the module IDs
and communication protocols for OBD2 modules in the vehicle.
1) Use the UP/DOWN scroll button to select Modules Present
from Diagnostic Menu and press OK button. (Figure 5.4)
2) View modules present with their IDs and communication
protocols.
Figure 5.54
3) Press the ESC button to return to previous menu
5.11 Code Breaker
Code breaker function is used to provide descriptions of DTCs
and helpful tips to deal with DTCs. It is useful for technicians to
find the root cause of trouble code faster, saving diagnosis and
repair time.
1) Repeat steps in the Read Codes section to identify DTCs.
(Figure 5.55)
Modules Present
ID Protocol
_________________________
$00 ISO 9141-2 ?
