3) Wait a few seconds while the scan tool reads vehicle information.

Figure 5.51

 If the vehicle does not support this mode, a message shows on

the display warning that the mode is not supported.

4) From Vehicle Info. Menu, use the UP/DOWN scroll button to

select an available item to view and press the OK button.

Figure 5.52

5) View retrieved vehicle information on screen.

Figure 5.53

6) Press the ESC button to return to previous menu.

Vehicle Info. 3/3

Vehicle ID Number

Calibration ID

Cal. Verf. Number

CVN1: BB BA A0 78

Vehicle Info.

Reading info…

- Please Wait -
