39
Figure 5.17
The number “x” to the upper right corner of the screen
indicates sequence of highlighted item; and “#x” are the order
that the parameters are selected and will be displayed.
If you want to deselect all marked items or select all items,
press the LEFT button. A message comes up to ask for your
confirmation.
Figure 5.18
If you decide to deselect these items, press OK; if you decide
not to, press ESC or use the LEFT/RIGHT scroll button to
select NO to continue PID selections.
4) Press the OK button to view selected PIDs on screen.
…………..Custom Data Set 4/26
DTC_CNT
FUELSYS1
FUELSYS2 ?
LOAD_PCT #01
ECT
SHRTFT1
………………Deselect All………………….
Deselect all
selected PID’s?
YES NO
