46
Playback Data
The Playback Data function allows viewing of previously stored
PID data.
1) To playback recorded data, use the UP/DOWN scroll button to
select Playback Data from Live Data menu and press the OK
button. (Figure 5.12)
You are also allowed to playback recorded data immediately
after recording.
2) Use the UP/DOWN button to select the memory location
marked with an asterisk (*) icon.
Figure 5.28
If there is no recording in selected location, a message “Not
Supported or Stored No Data” displays on the screen.
3) Use the UP/DOWN button to view recorded PIDs of each frame.
Figure 5.29
1 of 135 frame …
6
DTC_CNT 0
FUELSYS1 OL
FUELSYS2 N/A
LOAD_PCT (%) 0.0 ?
ETC(℃) -40
SHRTFT1(%) 99.2
Select Memory 3/3
Location #1 *
Location #2 ?
Location #3 *
