Autel Autolink AL519 [60/73] Use the up down scroll button to select the desired monitor from on board mon test menu and press the ok button

6) Use the UP/DOWN scroll button to select the desired monitor

from On-Board Mon. Test menu and press the OK button.

7) View test data on screen.

Figure 5.44

NOTE: If the On-Board Monitor Test failed, this monitor item

will be red color. Just by the text color you may easily find out

which system is at fault.

Figure 5.45

Figure 5.46

HO2S11 Voltage amplitu

ID 11

MOD $10

TEST(volts) 400 ?

MIN(volts) 1E1

MAX(volts) -----

STS OK

EVAP monitor

Phase 0 Initial tank vacuum an..

Phase 0 Initial tank vacuum

ID 00

MOD $10

TEST(in H2O) 0000 ?

MIN(in H2O) 7000

MAX(in H2O) 7200

STS Fail
