42
The asterisk (*) icon on the screen indicates that there is a
previous recording in the memory location.
If you select a location marked with an asterisk (*) icon, a
message prompting to overwrite old recording displays.
Figure 5.23
If you wish to proceed with overwriting the old recording,
press the OK button; if you do not wish to overwrite it, use
the LEFT/RIGHT button to select NO or press the ESC
button to pick another memory location.
4) Observe on-screen instructions.
If Manual Trigger is selected, following screen shows:
Figure 5.24
If DTC Trigger is selected, following screen shows:
……………Manual Trigger……………...
Ready to record!
Press [ENTER] to
start recording…
Press [ESC] to exit
Select Memory ...
A previous recording
exists! Do you want
to overwrite it?
YES NO
