57
test results for emission-related power train components and
systems that are and are not continuously monitored.
The scan tool allows access to the results of on-board diagnostic
monitoring tests for specific components/systems. The vehicle
manufacturer is responsible for assigning "Manufacturer Defined
Test IDs" and Component IDs for tests of different systems and
components. The advanced feature of this scan tool enables you to
read the definition of an On-Board Diagnostic Monitor ID.
NOTE: The scan tool will display a Test definition only if this test
definition is present in the vehicle’s computer memory. If no such
definition is present, the scan tool will just display the Test IDs.
In this test, there are typically a minimum value, a maximum value,
and a current value for each monitor. By comparing the current value
with the minimum and maximum value, the scan tool will determine
if it is OK.
1) Use the UP/DOWN scroll button to select On-Board Mon.
Test from Diagnostic Menu and press the OK button. (Figure
5.4)
2) Wait a few seconds while the scan tool validates the PID MAP.
3) The scan tool will prompt you to select the vehicle make.
Figure 5.40
4) After you select the vehicle manufacturer, the scan tool shows
the On-Board Monitors test results for specific monitored
systems.
Vehicle Manufacturer 1/28
BUICK
BMW
CADILLAC ?
CHRYSLER
FORD
GM
