ioLogik W5300 Modbus/TCP Address Mapping
C-9
Reference Address Data Type Description
40058 0x0039 1 word CH4 DO Pulse High Signal Width Lo- Word
40059 0x003A 1 word CH5 DO Pulse High Signal Width Hi- Word
40060 0x003B 1 word CH5 DO Pulse High Signal Width Lo- Word
40061 0x003C 1 word CH6 DO Pulse High Signal Width Hi- Word
40062 0x003D 1 word CH6 DO Pulse High Signal Width Lo- Word
40063 0x003E 1 word CH7 DO Pulse High Signal Width Hi- Word
40064 0x003F 1 word CH7 DO Pulse High Signal Width Lo- Word
40065 0x0040 1 word CH8 DO Pulse High Signal Width Hi- Word (Relay)
40066 0x0041 1 word CH8 DO Pulse High Signal Width Lo- Word (Relay)
40067 0x0042 1 word CH9 DO Pulse High Signal Width Hi- Word (Relay)
40068 0x0043 1 word CH9 DO Pulse High Signal Width Lo- Word (Relay)
40073 0x0048 1 word CH0 DO Mode 0: DO
1: Pulse
40074 0x0049 1 word CH1 DO Mode 0: DO
1: Pulse
40075 0x004A 1 word CH2 DO Mode 0: DO
1: Pulse
40076 0x004B 1 word CH3 DO Mode 0: DO
1: Pulse
40077 0x004C 1 word CH4 DO Mode 0: DO
1: Pulse
40078 0x004D 1 word CH5 DO Mode 0: DO
1: Pulse
40079 0x004E 1 word CH6 DO Mode 0: DO
1: Pulse
40080 0x004F 1 word CH7 DO Mode 0: DO
1: Pulse
40081 0x0050 1 word CH8 DO Mode 0: DO (Relay)
1: Pulse
40082 0x0051 1 word CH9 DO Mode 0: DO (Relay)
1: Pulse
40085 0x0054 1 word CH0 DI Count Filter
40086 0x0055 1 word CH1 DI Count Filter
40087 0x0056 1 word CH2 DI Count Filter
40088 0x0057 1 word CH3 DI Count Filter
40089 0x0058 1 word CH4 DI Count Filter
40090 0x0059 1 word CH5 DI Count Filter
40091 0x005A 1 word CH6 DI Count Filter
40092 0x005B 1 word CH7 DI Count Filter
40097 0x0060 1 word CH0 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40098 0x0061 1 word CH1 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
40099 0x0062 1 word CH2 DI Mode
0: DI
1: Count
Others : return Illegal Data Value
