Loewe Digital Recorder + [11/22] Archive recording
![Loewe Digital Recorder + [11/22] Archive recording](/views2/1020526/page11/bgb.png)
11 -
english
Archive recording
Timer recording
You can programme timer recordings for the Digital Recorder conveniently
using the EPG, teletext or manually. Up to 50 simultaneous timer entries are
possible.
When you have programmed timer recordings, the TV set can only be switched
off to the standby mode.
Never switch the TV set off at the mains and do not pull out the plug of the
TV set out of the socket. Otherwise no timer recordings can be made!
If a timer recording is being carried out in the standby mode, then the display
on the set shows orange and the DR
+
display also shows red.
Programmed timers for the Digital Recorder are displayed in the timer over-
view.
The abbreviation DR for Digital Recorder appears in place of the programme name
in the case of scrambled recordings which still have to be descrambled.
Call Timer list.
Completed timer recordings of the Digital Recorder are shown in the DR
archive.
A red dot with a key symbol appears in front of the entry for scrambled
recordings still to be descrambled.
Red button: Call DR-archive.
➠ The specied free capacity refers to recordings of analogue and DVB
programmes. A lot more memory space is required on the hard disk for
HDTV programmes.
Programming a timer recording with the EPG
Call EPG.
56Flag the broadcast to be recorded.
Press the red button to programme the broadcast as a timer
recording. The record dialogue box opens.
Check the timer data, change if necessary and conrm
with OK.
See page 13 for explanations of the setting options in the Timer data
menu.
In the EPG a red dot is set in front of the title of the programme.
If a programme has been agged with a red dot you can use the red button
to delete the programmed timer again. The red dot disappears.
END
INFO
Timer list Fri 29.09./08:28
Fri 29.09. 21:45-23:00 3sat AVO-Session Basel
Sat 30.09. 02:00-03:55 DR Top-Movie 1
Sat 30.09. 20:15-22:20 Premiere... Top-Movie 2
Change
Delete
New recording
END
INFO
MENU
DR archive free capacity 48:42 hrs
29.09 Premiere HD Top-Movie 1
14.09 Phoenix Bon(n) jour Berlin
31.08 Das Erste da capo
29.07 3sat tagesschau
00.00 LOEWE. HDTV/sound demo
Kultur pur
Edit/protect
delete/copy
Sort alphabetically
TEXT
Detail View
OK
OK
END
MENU
P+
P–
TEXT
OK
0 9
-
OK
arte 15:57-16:59 Charmed - Zauberhafte Hexen
Das Erste 16:00-16:10 Tagesschau
ZDF 16:00-16:10 heute - in Europa
WDR Köln 16:00-16:15 WDR aktuell
Bayerisches... 16:00-16:05 Rundschau
hr-fernsehen 16:00-16:30 Schlemmerreise Spanien
MDR FERNS... 16:00-16:15 Hier ab vier
NDR FS HH 16:00-16:30 Tipps und Trends - Der Verbraucher...
SWR Fernse... 16:00-16:05 Baden-Württemberg aktuell
2 ZDF
EPG (Electronic Programme Guide) Mon 31.07./16:05
Detail View Record
Page ↑↓ Select time Select date, ... , topics
Date
Time
Stations
Topics
Mon 31.07.
now
all
all
until 17:00 17:00 18:00 19:00
Charmed - Zauberhafte Hexen
END
INFO
OK
OK
Timer data
15:57 Charmed - Zauberhafte Hexen
Lock movie
Set delete protection
confirm
DVD-REC
Recorder DR
Station 23 arte
Date 30.09.2007
Recording time 15:57 until 16:59
VPS no
Recording type once only
