Loewe Digital Recorder + [14/22] Archive playback
![Loewe Digital Recorder + [14/22] Archive playback](/views2/1020526/page14/bge.png)
- 14
english
Archive playback
You can nd a directory of your recordings in the DR archive. You can start play-
back, delete, copy or decode recordings from this list. Using Edit/protect you
can change the name of an archive and set or remove a delete protection.
Red button (for MHEG-5 ASSIST button): Call DR archive.
Blue button: Switch between alphabetical and time sorting.
The progress bar shows you how much of the recording has been watched.
If other programme data is available from the EPG or teletext these are shown
below the archive list for the entry just agged. Other information about the
recording can be called with the TEXT button, if this is offered.
Explanations of the symbols in the DR archive
Recording with manually set bookmarks.
Recording with set delete protection.
Recording with set parental lock.
Coded recording.
Red dot at the beginning of the line: Recording is played over/copied
(see page 18, “Copying recordings from the archive”).
Red dot with key symbol at the beginning of the line: Descramble
recording (see page 18, “Descramble scrambled recording”).
Playing from the DR archive
56 Select the recording.
OK Start playback.
➠ The CA module with Smart Card must be plugged in when playing recor-
dings which are still coded.
Setting bookmarks
While playing an archive recording, you can set bookmarks by pressing the
PLAY button for a little longer. You will see the bookmark set message. The
drive display is then faded in and you will see the set bookmark above the bar
for the playback. You can set up to 15 bookmarks per recording.
This makes these places easy to nd later.
PLAY button (press for a little longer): Set bookmark.
➠ Automatically set bookmarks are grey. Manually set
bookmarks are blue.
Jumping to bookmarks
END: Show the drive display during archive playback.
Blue button: Bookmark forwards.
Red button: Bookmark backwards.
Delete individual bookmarks
Jump with the red or blue button to the manually set book-
mark to be deleted.
Press PLAY button for a little longer, the bookmark is de-
leted.
END
INFO
MENU
DR archive free capacity 48:42 hrs
08.10 Das Erste da capo
29.09 Phoenix Bon(n) jour Berlin
14.09 3sat AVO-Session Basel
20.08 Das Erste Brisant
18.08 Premiere Frau mit Schleier
00.00 LOEWE. HDTV/sound demo
Kultur pur
Edit/protect
delete/copy
Sort alphabetically
TEXT
Detail View
Highlights
OK
OK
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:24
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:17
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:11
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:17
00:00 1:03
Bookmark ← Bookmark →Highlights
Language/sound
Archive 31.08.
da capo
00:03
