17 -
english
Archive playback
Hiding sections of the recording
You can hide sections of an archive recording. For future playback and when
copying to a DVD or video recorder, the hidden sections are skipped.
Press the PAUSE button at the point in the archive playback
from where the hiding should start.
Yellow button: Call Delete/hide.
Yellow button: Set the start of the section to be hidden.
Press PLAY button or
PAUSE button to continue playback.
Press the yellow button when you want to end hiding.
The hidden section of the recording is shaded in the bar.
If you start playback again before the beginning of the hidden
section, the hidden section is skipped.
If the setting in the Digital Recorder menu →Inform about
hidden sections is set to yes, you will see the message A
faded area was skipped.
With the blue button you can show the hidden section again
continuously.
Deleting bookmarks
You can delete all manually set bookmarks. Bookmarks that were set automati-
cally at the beginning and the end of a broadcast cannot be deleted.
➠ Manually set bookmarks are blue, automatically set bookmarks are dis-
played in grey.
Press PAUSE button during archive playback.
Yellow button: Call Delete/hide.
Blue button: Delete manually set bookmarks.
Press PLAY button or
PAUSE button to continue playback.
Automatically set bookmarks are not deleted.
In addition, you have the option of deleting the bookmarks
via DR archive → delete/copy (see page 19).
00:00 1:03
DR archive Delete/hide
Archive 31.08.
da capo
00:11
00:00 1:03
Delete from here to start
Delete from here to end
Set hiding start
Delete bookmark
Archive 31.08.
da capo
00:11
00:00 1:03
Set hiding end
Cancel hiding
Archive 31.08.
da capo
00:11
00:00 1:03
Set hiding end
Cancel hiding
Archive 31.08.
da capo
00:11
Bookmark ← Bookmark →Highlights
Language
00:00 1:03
Archive 31.08.
da capo
00:24
00:00 1:03
DR archive Delete/hide
Archive 31.08.
da capo
00:11
00:00 1:03
Delete from here to start
Delete from here to end
Set hiding start
Delete bookmark
Archive 31.08.
da capo
00:11
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:11
