15 -
english
Archive playback
For instance, you are searching for the beginning of the section where a por-
tion of the recording is to be hidden.
8Press repeatedly to jump forward (pre-set jump
distance).
If you have jumped past the desired part of the recording,
jump in the opposite direction:
7 This jump in the opposite direction is only carried
out for half the jump distance . Now press 7 to
jump back out of the area that is to be hidden.
If in the process you jump past the place where you want to
start the hide process, then jump forward using 8. In the
process, the jump distance is cut in half again.
By halving the jump distance when changing direction again
you can nd your way to a specic place.
The pre-set jump distance is then used again if you jump
in the same direction more than three times or if the drive
display disappears.
Fast forward and rewind
During time shift viewing you can fast forward and rewind at three different
speeds (when viewing HDTV rewind is not possible). Sound is not audible
during winding.
Press the button 8 or 7 a little longer.
Increase speed: Briey press button repeatedly.
The speed increases every time you press the button until
eventually switching back to the initial speed.
Press the PLAY button, when you have reached the position
where you want to continue viewing.
You will see a freeze picture when you reach the end of the
recording. When rewinding reaches the beginning, the Digital
Recorder switches to playback mode.
➠ When playing coded recordings, some of the following functions are
restricted.
Playing highlights
If there are manually set bookmarks in the current playback, they can be played
as highlights. 30 seconds before and after the set bookmark are played. The
highlights are numbered consecutively and shown continuously.
The playing of highlights can be terminated by pressing the STOP button.
END: Show status display.
Press the PLAY button for Highlights.
Start playing highlights. As long as this drive display is shown, you jump to the
next highlight with the blue button and the red button jumps to the previous
highlight. You can also jump to the next highlight by pressing the PLAY button
again. This function is also available if no drive display is shown. The playing
of highlights can be terminated by pressing the STOP button.
Further information concerning highlight playback can be found on page 19.
Jumping
You can jump by briey pressing the buttons 7 or 8.
8Jump forwards.
7 Jump backwards.
➠ Setting the jump distance: see page 6.
Smart Jump
The Smart Jump function is included to enable fast and easy access to a certain
place within the recording which is currently being played. The factory setting
has Smart Jump switched on.
With switched on Smart Jump every time the direction is changed the jump
distance is cut in half.
The playback symbol4is yellow when the Smart Jump function is active.
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:11
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:11
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:13
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:11
Archive 31.08.
da capo
00:15
00:00 1:03
Archive 31.08.
da capo
00:38
00:00 1:03
00:00 1:03
Bookmark ← Bookmark →Highlights
Language
Archive 31.08.
da capo
00:51
